Shackle parts
-
Products
-
American standard shackles
Add time：2021-12-24 14:52:56
Number of views：1210
| Size (in) |
W.L.L (t) |
Weight (lbs.) |
Dimensions(in) |
Tolerance +/- |
| A |
B |
D |
E |
F |
G |
|
w |
L |
w |
P |
D |
A |
| 3/16 |
1/3 |
0.06 |
0.38 |
0.25 |
0.88 |
0.19 |
0.60 |
0.56 |
0.98 |
1.47 |
0.16 |
1.14 |
0.19 |
0.06 |
0.06 |
| 1/4 |
1/2 |
0.10 |
0.47 |
0.31 |
1.13 |
0.25 |
0.78 |
0.61 |
1.278 |
1.84 |
0.19 |
1.43 |
0.25 |
0.06 |
0.06 |
| 5/16 |
3/4 |
0.19 |
0.53 |
0.38 |
1.22 |
0.31 |
0.84 |
0.75 |
1.47 |
2.09 |
0.22 |
1.71 |
0.31 |
0.06 |
0.06 |
| 3/8 |
1 |
0.31 |
0.66 |
0.44 |
1.44 |
0.38 |
1.03 |
0.91 |
1.78 |
2.49 |
0.25 |
2.02 |
0.38 |
0.13 |
0.06 |
| 7/16 |
1-1/2 |
0.38 |
0.75 |
0.50 |
1.69 |
0.44 |
1.16 |
1.06 |
2.03 |
2.91 |
0.31 |
2.37 |
0.44 |
0.13 |
0.06 |
| 1/2 |
2 |
72 |
0.81 |
0.63 |
1.88 |
0.50 |
1.31 |
1.19 |
2.31 |
3.28 |
0.38 |
2.69 |
0.50 |
0.13 |
0.06 |
| 5/8 |
3-1/4 |
1.37 |
1.06 |
0.75 |
2.38 |
0.63 |
1.69 |
1.50 |
2.94 |
4.19 |
0.44 |
3.34 |
0.69 |
0.13 |
0.06 |
| 3/4 |
4-3/4 |
2.35 |
1.25 |
0.88 |
2.81 |
0.75 |
2.00 |
1.81 |
3.50 |
4.97 |
0.50 |
3.97 |
0.81 |
0.13 |
0.06 |
| 7/8 |
6-1/2 |
3.62 |
1.44 |
1.00 |
3.31 |
0.88 |
2.28 |
2.09 |
4.03 |
5.83 |
0.50 |
4.50 |
0.97 |
0.25 |
0.06 |
| 1 |
8-1/2 |
5.03 |
1.69 |
1.13 |
3.75 |
1.00 |
2.69 |
2.38 |
4.69 |
6.56 |
0.56 |
5.13 |
1.06 |
0.25 |
0.06 |
| 1-1/8 |
9-1/2 |
7.41 |
1.81 |
1.25 |
4.25 |
1.16 |
2.91 |
2.69 |
5.16 |
7.47 |
0.63 |
5.71 |
1.25 |
0.25 |
0.06 |
| 1-1/4 |
12 |
9.50 |
2.03 |
1.38 |
4.69 |
1.29 |
3.25 |
3.00 |
5.75 |
8.25 |
0.69 |
6.25 |
1.38 |
0.25 |
0.06 |
| 1-3/8 |
13-1/2 |
13.53 |
2.25 |
1.50 |
5.25 |
1.42 |
3.63 |
3.31 |
6.38 |
9.16 |
0.75 |
6.83 |
1.50 |
0.25 |
0.13 |
| 1-1/2 |
17 |
17.20 |
2.38 |
1.63 |
5.75 |
1.54 |
3.88 |
3.63 |
6.88 |
10.00 |
0.81 |
7.33 |
1.62 |
0.25 |
0.13 |
| 1-3/4 |
25 |
27.78 |
2.88 |
2.00 |
7.00 |
1.84 |
5.00 |
4.19 |
8.86 |
12.34 |
1.00 |
9.06 |
2.25 |
0.25 |
0.13 |
| 2 |
35 |
45.00 |
3.25 |
2.25 |
7.75 |
2.08 |
5.75 |
4.81 |
9.97 |
13.68 |
1.22 |
10.35 |
2.40 |
0.25 |
0.13 |
| 2-1/2 |
55 |
85.75 |
4.13 |
2.75 |
10.50 |
2.71 |
7.25 |
5.69 |
12.87 |
17.84 |
1.38 |
13.00 |
3.13 |
0.25 |
0.25 |
